Micron 7450 NVMe SSD
Introducing the Micron 7450 NVMe SSD - available in an array of form factors, capacity sizes, and deployment options that are optimized for your boot, cache, and storage needs.
With the new 176-layer TLC NAND, the Micron 7450 offers 3 different form factors - E1.S, M.2, and U.3, and is available in several capacities ranging from 400GB to 15.36TB.
Be sure to take a look at the part numbers below to see the available specifications and contact us to speak with our Micron FAE or a sales expert for personal assistance selecting the best drive to meet your requirements.
Features & Benefits:
- Built on the world's most advanced 176-layer NAND
- Yields read and write speeds up to 1 million IOPS
- Sequential performance up to 6800MB/s
- Delivers 2ms and lower latency for 99.9999%
7450 SSD With NVMe
| PART NUMBER | FORM FACTOR | CAPACITY | SECURITY ENCRYPTION |
|---|---|---|---|
| MTFDKBZ3T8TFR-1BC1ZABYY | E1.S (5.9mm) | 3.84TB | NON-SED |
| MTFDKBZ960TFR-1BC15ABYY | E1.S (5.9mm) | 960GB | TCG OPAL |
| MTFDKCE960TFR-1BC15ABYY | E1.S (15mm) | 960GB | TCG OPAL |
| MTFDKBZ1T9TFR-1BC15ABYY | E1.S (5.9mm) | 1.92TB | TCG OPAL |
| MTFDKCE1T9TFR-1BC15ABYY | E1.S (15mm) | 1.92TB | TCG OPAL |
| MTFDKBZ3T8TFR-1BC15ABYY | E1.S (5.9mm) | 3.84TB | TCG OPAL |
| MTFDKCE3T8TFR-1BC15ABYY | E1.S (15mm) | 3.84TB | TCG OPAL |
| MTFDKBZ7T6TFR-1BC15ABYY | E1.S (5.9mm) | 7.68TB | TCG OPAL |
| MTFDKCE7T6TFR-1BC15ABYY | E1.S (15mm) | 7.68TB | TCG OPAL |
| MTFDKBA480TFR-1BC1ZABYY | M.2 (22x80) | 480GB | NON-SED |
| MTFDKBA960TFR-1BC1ZABYY | M.2 (22x80) | 960GB | NON-SED |
| MTFDKBG960TFR-1BC1ZABYY | M.2 (22x110) | 960GB | NON-SED |
| MTFDKBG960TFR-1BC1ZABYY | M.2 (22x110) | 960GB | NON-SED |
| MTFDKBG1T9TFR-1BC1ZABYY | M.2 (22x110) | 1.92TB | NON-SED |
| MTFDKBG3T8TFR-1BC1ZABYY | M.2 (22x110) | 3.84TB | NON-SED |
| MTFDKBA480TFR-1BC15ABYY | M.2 (22x80) | 480GB | TCG OPAL |
| MTFDKBA960TFR-1BC15ABYY | M.2 (22x80) | 960GB | TCG OPAL |
| MTFDKBG960TFR-1BC15ABYY | M.2 (22x110) | 960GB | TCG OPAL |
| MTFDKBG1T9TFR-1BC15ABYY | M.2 (22x110) | 1.92TB | TCG OPAL |
| MTFDKBG3T8TFR-1BC15ABYY | M.2 (22x110) | 3.84TB | TCG OPAL |
| MTFDKCB960TFR-1BC1ZABYY | U.3 (7mm) | 960GB | NON-SED |
| MTFDKCC960TFR-1BC1ZABYY | U.3 (15mm) | 960GB | NON-SED |
| MTFDKCB1T9TFR-1BC1ZABYY | U.3 (7mm) | 1.92TB | NON-SED |
| MTFDKCC1T9TFR-1BC1ZABYY | U.3 (15mm) | 1.92TB | NON-SED |
| MTFDKCB3T8TFR-1BC1ZABYY | U.3 (7mm) | 3.84TB | NON-SED |
| MTFDKCC3T8TFR-1BC1ZABYY | U.3 (15mm) | 3.84TB | NON-SED |
| MTFDKCB7T6TFR-1BC1ZABYY | U.3 (7mm) | 7.68TB | NON-SED |
| MTFDKCC7T6TFR-1BC1ZABYY | U.3 (15mm) | 7.68TB | NON-SED |
| MTFDKCC15T3TFR-1BC1ZABYY | U.3 (15mm) | 15.36TB | NON-SED |
| MTFDKCB960TFR-1BC15ABYY | U.3 (7mm) | 960GB | TCG OPAL |
| MTFDKCC960TFR-1BC15ABYY | U.3 (15mm) | 960GB | TCG OPAL |
| MTFDKCB1T9TFR-1BC15ABYY | U.3 (7mm) | 1.92TB | TCG OPAL |
| MTFDKCC1T9TFR-1BC15ABYY | U.3 (15mm) | 1.92TB | TCG OPAL |
| MTFDKCB3T8TFR-1BC15ABYY | U.3 (7mm) | 3.84TB | TCG OPAL |
| MTFDKCC3T8TFR-1BC15ABYY | U.3 (15mm) | 3.84TB | TCG OPAL |
| MTFDKCB7T6TFR-1BC15ABYY | U.3 (7mm) | 7.68TB | TCG OPAL |
| MTFDKCC7T6TFR-1BC15FCYY | U.3 (15mm) | 7.68TB | TCG OPAL |
| MTFDKCC7T6TFR-1BC15ABYY | U.3 (15mm) | 7.68TB | TCG OPAL |
| MTFDKCC15T3TFR-1BC15ABYY | U.3 (15mm) | 15.36TB | TCG OPAL |
| PART NUMBER | FORM FACTOR | CAPACITY | SECURITY ENCRYPTION |
|---|---|---|---|
| MTFDKBA400TFS-1BC1ZABYY | M.2 (22x80) | 400GB | NON-SED |
| MTFDKBA800TFS-1BC1ZABYY | M.2 (22x80) | 800GB | NON-SED |
| MTFDKCB800TFS-1BC1ZABYY | U.3 (7mm) | 800GB | NON-SED |
| MTFDKCC800TFS-1BC1ZABYY | U.3 (15mm) | 800GB | NON-SED |
| MTFDKCB1T6TFS-1BC1ZABYY | U.3 (7mm) | 1.6TB | NON-SED |
| MTFDKCC1T6TFS-1BC1ZABYY | U.3 (15mm) | 1.6TB | NON-SED |
| MTFDKCB3T2TFS-1BC1ZABYY | U.3 (7mm) | 3.2TB | NON-SED |
| MTFDKCC3T2TFS-1BC1ZABYY | U.3 (15mm) | 3.2TB | NON-SED |
| MTFDKCB6T4TFS-1BC1ZABYY | U.3 (7mm) | 6.4TB | NON-SED |
| MTFDKCC6T4TFS-1BC1ZABYY | U.3 (15mm) | 6.4TB | NON-SED |
| MTFDKCC12T8TFS-1BC1ZABYY | U.3 (15mm) | 12.8TB | NON-SED |
| MTFDKCB800TFS-1BC15ABYY | U.3 (7mm) | 800GB | TCG OPAL |
| MTFDKCC800TFS-1BC15ABYY | U.3 (15mm) | 800GB | TCG OPAL |
| MTFDKCB1T6TFS-1BC15ABYY | U.3 (7mm) | 1.6TB | TCG OPAL |
| MTFDKCC1T6TFS-1BC15ABYY | U.3 (15mm) | 1.6TB | TCG OPAL |
| MTFDKCC3T2TFS-1BC15ABYY | U.3 (15mm) | 3.2TB | TCG OPAL |
| MTFDKCC6T4TFS-1BC15ABYY | U.3 (15mm) | 6.4TB | TCG OPAL |
| MTFDKCC12T8TFS-1BC15ABYY | U.3 (15mm) | 12.8TB | TCG OPAL |
Design flexible #datacenters with the new 7450, Micron?s 176-layer #NAND SSD, available in multiple form factors and offering unmatched performance for #cloud applications: https://t.co/p7hHBuq4Oh pic.twitter.com/gQInErVInM
— Micron Technology (@MicronTech) March 2, 2022
Not sure if the 7450 is the right fit, or looking for a SATA SSD? Edge Electronics is an authorized distributor of storage solutions by Micron. Visit our Micron SSD Guide for an overview of all the currently available Micron SSD series.
