EOL transition guide · Published
Transitioning from the Micron 7450 & 7500 Series to the Micron 7600 SSD Series
Compare Micron 7600 candidates for an existing 7450 or 7500 application. Review host, form factor, configuration, and qualification requirements.
Considering a move from a Micron 7450 or 7500 SSD to the 7600? Start with your current part number, host configuration, and workload requirements. We help compare product options and arrange samples for evaluation.
The Micron 7600 is a PCIe Gen5 NVMe SSD family built with Micron G9 NAND. Review the model and capacity specifications for your workload.
FAQ
Below are answers to some frequently asked questions regarding the transition to the new Micron 7600.
What is the difference between the Micron 7450 and Micron 7600 SSDs?
The Micron 7600 is a next-generation drive offering step-change improvements over the 7450 series, most notably:
- PCIe Gen5 interface (vs PCIe Gen4 for 7450), delivering much higher sequential and random throughput
- Advanced Micron G9 NAND for improved performance, power efficiency, and low latency
- Enhanced feature set, including FIPS 140-3 Level 2 certifiable options, updated security protocols, and broader support for enterprise workloads
Are Micron 7600 SSDs backwards compatible with applications and systems that currently use the Micron 7450?
These are replacement options for your team to qualify. Check form factor, connector, host support, firmware, power, cooling, and security requirements. A migration may require changes to the design or storage configuration. A supported drive and host may negotiate a link at Gen4 speeds; that does not establish full system compatibility.
Does the Micron 7600 come in the M.2 form factor?
The Micron 7600 form-factor range does not include M.2. If your system requires M.2, contact us to review available options or discuss whether that requirement can change.
Micron 7450/7500 to 7600 SSD Candidate Replacements
These tables list candidate replacements by capacity, endurance class, form factor, and security configuration. Confirm the exact configuration and manufacturer documentation before qualification.
7450 = Source from 7450 series
7500 = Source from 7500 series
PRO Endurance • U.2 Form Factor • TCG OPAL Security
High-performance encrypted drives with standard endurance
| 7450 part number | 7500 part number | 7600 candidate replacement | Capacity |
|---|---|---|---|
| MTFDKCC1T9TFR-1BC15ABYY | MTFDKCC1T9TGP-1BK1DABYY | MTFDLAL1T9THG-1BP1DFCYY | 1.92TB |
| MTFDKCC3T8TFR-1BC15ABYY | MTFDKCC3T8TGP-1BK1DABYY | MTFDLAL3T8THG-1BP1DFCYY | 3.84TB |
| MTFDKCC7T6TFR-1BC15ABYY | MTFDKCC7T6TGP-1BK1DABYY | MTFDLAL7T6THG-1BP1DFCYY | 7.68TB |
| MTFDKCC15T3TFR-1BC15ABYY | MTFDKCC15T3TGP-1BK1DABYY | MTFDLAL15T3THG-1BP1DFCYY | 15.36TB |
MAX Endurance • U.2 Form Factor • TCG OPAL Security
High-endurance encrypted drives for write-intensive workloads
| 7450 part number | 7500 part number | 7600 candidate replacement | Capacity |
|---|---|---|---|
| MTFDKCC1T6TFS-1BC15ABYY | MTFDKCC1T6TGQ-1BK1DABYY | MTFDLAL1T6THS-1BP1DFCYY | 1.6TB |
| MTFDKCC3T2TFS-1BC15ABYY | MTFDKCC3T2TGQ-1BK1DABYY | MTFDLAL3T2THS-1BP1DFCYY | 3.2TB |
| MTFDKCC6T4TFS-1BC15ABYY | MTFDKCC6T4TGQ-1BK1DABYY | MTFDLAL6T4THS-1BP1DFCYY | 6.4TB |
| MTFDKCC12T8TFS-1BC15ABYY | MTFDKCC12T8TGQ-1BK1DABYY | MTFDLAL12T8THS-1BP1DFCYY | 12.8TB |
PRO Endurance • U.2 Form Factor • NON-SED (Unencrypted)
Standard endurance drives without encryption
| 7450 part number | 7500 part number | 7600 candidate replacement | Capacity |
|---|---|---|---|
| MTFDKCC1T9TFR-1BC1ZABYY | MTFDKCC1T9TGP-1BK1JABYY | MTFDLAL1T9THG-1BP1JABYY | 1.92TB |
| MTFDKCC3T8TFR-1BC1ZABYY | MTFDKCC3T8TGP-1BK1JABYY | MTFDLAL3T8THG-1BP1JABYY | 3.84TB |
| MTFDKCC7T6TFR-1BC1ZABYY | MTFDKCC7T6TGP-1BK1JABYY | MTFDLAL7T6THG-1BP1JABYY | 7.68TB |
| MTFDKCC15T3TFR-1BC1ZABYY | MTFDKCC15T3TGP-1BK1JABYY | MTFDLAL15T3THG-1BP1JABYY | 15.36TB |
MAX Endurance • U.2 Form Factor • NON-SED (Unencrypted)
High-endurance drives without encryption
| 7450 part number | 7500 part number | 7600 candidate replacement | Capacity |
|---|---|---|---|
| MTFDKCC1T6TFS-1BC1ZABYY | MTFDKCC1T6TGQ-1BK1JABYY | MTFDLAL1T6THS-1BP1JABYY | 1.6TB |
| MTFDKCC3T2TFS-1BC1ZABYY | MTFDKCC3T2TGQ-1BK1JABYY | MTFDLAL3T2THS-1BP1JABYY | 3.2TB |
| MTFDKCC6T4TFS-1BC1ZABYY | MTFDKCC6T4TGQ-1BK1JABYY | MTFDLAL6T4THS-1BP1JABYY | 6.4TB |
| MTFDKCC12T8TFS-1BC1ZABYY | MTFDKCC12T8TGQ-1BK1JABYY | MTFDLAL12T8THS-1BP1JABYY | 12.8TB |
PRO E1.S • E1.S Form Factor • TCG OPAL Security
E1.S form factor encrypted drives with standard endurance
| Original Part Number (7450) | 7600 Candidate replacement | Capacity |
|---|---|---|
| 7450: MTFDKCE1T9TFR-1BC15ABYY | MTFDLCE1T9THG-1BP1DFCYY | 1.92TB |
| 7450: MTFDKCE3T8TFR-1BC15ABYY | MTFDLCE3T8THG-1BP1DFCYY | 3.84TB |
| 7450: MTFDKCE7T6TFR-1BC15ABYY | MTFDLCE7T6THG-1BP1DFCYY | 7.68TB |
MAX E1.S • E1.S Form Factor • NON-SED (Unencrypted)
E1.S form factor high-endurance drives without encryption
| Original Part Number (7450) | 7600 Candidate replacement | Capacity |
|---|---|---|
| 7450: MTFDKCE3T2TFS-1BC1ZABYY | MTFDLCE3T2THS-1BP1JABYY | 3.2TB |
| 7450: MTFDKCE6T4TFS-1BC1ZABYY | MTFDLCE6T4THS-1BP1JABYY | 6.4TB |
Looking to Upgrade to the Micron 7600 Series?
Contact Edge about the selected configuration, samples, current availability, and manufacturer technical questions.
