Digital View · LCD Controller Boards
DT-1920-HDMI-EDP
Manufacturer part number: 4176602XX-3
HDMI-to-eDP LCD controller with a standard HDMI connector. Supports panels up to 1920x1200; standard-connector variant 4176602XX-3.
In stock.
Authorized Digital View distributor
Specifications
Application & availability
- Target applications
- Monitors, Embedded displays
Video & display
- Input interfaces
- HDMI
- Video inputs and versions
- HDMI 1.4
- Maximum video input resolution
- 1920 × 1200
- Maximum video input refresh rate
- 60 Hz
- Panel interface
- eDP
- Panel output details
- eDP
- Supported resolutions
- Up to 1920 × 1200
- Color depth (bits per color)
- 8
- Image processing
- scaling, rotation, color-adjust
Integration & physical details
- Control interfaces
- OSD buttons, IR remote, RS-232, DDC/CI
- Audio output
- digital line-out (header), OSD volume control, not amplified
- Backlight control
- PWM (default) or D/A; VESA DPMS enable; PWM 100-440Hz
- Panel supply options
- 3.3V, 5V, 10V, 12V
- Supply voltage
- 12 or 24 V DC
- Power consumption (board only)
- 10 W
- Environment grade
- Standard
- Operating temperature
- 0 to 60 °C
- Board dimensions
- 91.4 × 91.4 mm (L x W)
Documents
PDFBrochureDigital View PDF
↓ PDFManualDigital View PDF
↓ Request pricing and availability4176602XX-3
We provide available lot-level traceability and manufacturer documentation for authorized-channel parts.
Send the quantity and your target date. We'll come back with pricing and availability.
Open the formFor documentation, pricing and availability: 800.647.3343.
